Weather

/** * The two weather documents and the yard they fall on. * * @remarks * Both are the shipped presets with the numbers this scene wants: a bigger volume, a rate that * fills it, and `renderer.lit` set from the panel's toggle. `lit` is a document field rather than a * component one because it changes the *generated program* — a lit particle reads * `mainLightDirection`, `mainLightColor` and `ambientColor`, and a program that never reads them * does not declare them. */import {  createMaterialAsset,  MeshAsset,  MeshRenderer,  ParticleSystem,  particleDefinition,  pbrMaterialDefinition,} from "ignifx";import { FollowsTheViewer } from "./volume.ts";import type { App, AssetHandle, Entity, ParticleAsset, ParticleDefinition } from "ignifx";/** The overcast near-black the frame is cleared to. */export const CLEAR_COLOR = { r: 0.035, g: 0.042, b: 0.055, a: 1 } as const;/** The opening shot: the pose every capture is taken from. */export const SHOT = {  fov: 46,  yaw: 26,  pitch: 10,  distance: 11,  target: { x: 0, y: 2.2, z: 0 },} as const;/** How wide the ground is, in metres. */export const FLOOR_SIZE = 90;/** * How many records each volume holds: the ring size, and therefore the ceiling on how many drops or * flakes can be in the air at once. */const CAPACITY = { rain: 1600, snow: 1000 } as const;/** How high each volume hangs above the ground, in metres, and whether it opens falling. */export const VOLUME = {  rain: { height: 12, enabled: true },  snow: { height: 9, enabled: false },} as const;/** * How wide each volume is, in metres. * * @remarks * Twenty-two is a compromise the capacity forces: the volume is centred on the **camera** and the * camera looks across it, so a narrow volume leaves the far half of the frame dry — but a wide one * spreads the same thousand drops over three times the ground and the rain stops reading as rain. */const VOLUME_SIZE = { x: 22, y: 0.2, z: 22 } as const;/** * The rain document. * * @param lit - Whether the drops are shaded by the scene's main light. * @returns The document. */export function rainDefinition(lit: boolean): ParticleDefinition {  return particleDefinition("rain", {    // A rate of 900 over a 1.4-second life keeps about 1,260 drops alive, inside the capacity: a    // system that emits faster than its capacity overwrites live particles, and counts each one in    // `droppedCount`.    main: { capacity: CAPACITY.rain },    emission: { rateOverTime: 900 },    shape: { kind: "box", size: VOLUME_SIZE },    start: { lifetime: 1.4, speed: { min: -9, max: -12 }, size: 0.035, color: [0.75, 0.85, 1, 0.75] },    renderer: { lit, speedScale: 0.06, lengthScale: 1.2 },  });}/** * The snow document. * * @param lit - Whether the flakes are shaded by the scene's main light. * @returns The document. */export function snowDefinition(lit: boolean): ParticleDefinition {  return particleDefinition("snow", {    // A flake lives up to eight seconds, so sixty a second keeps about 480 of them in the air.    main: { capacity: CAPACITY.snow },    emission: { rateOverTime: 60 },    shape: { kind: "box", size: VOLUME_SIZE },    start: { lifetime: { min: 5, max: 8 }, speed: { min: -1.2, max: -2.2 }, size: { min: 0.04, max: 0.09 } },    renderer: { lit },  });}/** Where the yard's posts stand and how tall each one is, in metres. */const POSTS: readonly { readonly x: number; readonly z: number; readonly height: number }[] = [  { x: -3.2, z: 1.4, height: 3.4 },  { x: 2.6, z: -2.2, height: 2.2 },  { x: 5.4, z: 3.1, height: 4.1 },  { x: -6.1, z: -4.3, height: 2.8 },  { x: 0.4, z: 6.2, height: 3.1 },  { x: -8.4, z: 5.5, height: 2.4 },];/** * Stands a few posts in the yard, so the weather has something to fall in front of and behind. * * @param app - The app the entities belong to. */export function createPosts(app: App): void {  const mesh = MeshAsset.box(app, { size: 1 });  const material = createMaterialAsset(    app,    pbrMaterialDefinition({      name: "weather/post",      baseColor: { r: 0.21, g: 0.19, b: 0.17, a: 1 },      metallic: 0,      roughness: 0.85,    }),    [],  );  for (const post of POSTS) {    const entity = app.world.createEntity("Post", { position: { x: post.x, y: post.height / 2, z: post.z } });    entity.transform.localScale.set(0.34, post.height, 0.34);    entity.addComponent(MeshRenderer, { mesh: mesh.retain(), materials: [material.retain()], castShadows: true });  }}/** One weather volume: the entity that carries it, and the system that fills it. */export interface Volume {  /** The emitter's entity, whose rotation is the wind. */  readonly entity: Entity;  /** The system playing the document. */  readonly system: ParticleSystem;}/** What {@link createVolume} takes. */export interface VolumeOptions {  /** The entity's name. */  readonly name: string;  /** The document it opens with. */  readonly definition: AssetHandle<ParticleAsset>;  /** How high it hangs, in metres. */  readonly height: number;  /** Whose position it stands over. */  readonly target: Entity;  /** The emission seed. */  readonly seed: number;  /** Whether it is falling to begin with. */  readonly enabled: boolean;}/** * Hangs one weather volume over the viewer. * * @remarks * `playOnAwake` is off and `main.ts` plays it a frame later, because a world-space document bakes * the emitter's matrix into every record as it is written — and a `prewarm` on the very first frame * would run before the volume has been told where it is. * * @param app - The app the entity belongs to. * @param options - The document, the height, whom to follow, the seed and whether it starts on. * @returns The entity and its system. */export function createVolume(app: App, options: VolumeOptions): Volume {  const entity = app.world.createEntity(options.name, { position: { x: 0, y: options.height, z: 0 } });  const follow = entity.addComponent(FollowsTheViewer, { height: options.height });  follow.target = options.target;  const system = entity.addComponent(ParticleSystem, {    definition: options.definition,    seed: options.seed,    playOnAwake: false,  });  system.enabled = options.enabled;  return { entity, system };}/** * The toggle handler for one volume: it turns the component off and on, and starts it the first * time it is turned on. * * @param system - The volume's system. * @returns What the toggle calls. */export function falls(system: ParticleSystem): (on: boolean) => void {  return (on: boolean): void => {    system.enabled = on;    if (on) {      start(system);      return;    }    // A disabled system is frozen, not empty: its clock stops and its records stay in the ring.    // Clearing them is what makes the counter agree with the sky.    system.stop({ clear: true });  };}/** * Starts one volume if it is on and not already falling. * * @param system - The volume's system. */export function start(system: ParticleSystem): void {  if (system.enabled && !system.isPlaying) {    // A looping `prewarm` document fills its whole volume inside this call, so the storm is never    // seen filling up from an empty sky.    system.play();  }}/** * Puts one document on a volume, and starts the fresh emitter it builds. * * @param system - The volume's system. * @param definition - The document to play. */export function setDocument(system: ParticleSystem, definition: AssetHandle<ParticleAsset>): void {  if (system.definition === definition) {    return;  }  // A different document is a different effect: the component builds a new emitter for it, and the  // new one has to be told to play. The drops already in the air are the old emitter's and go with  // it.  system.definition = definition;  if (system.enabled) {    system.play();  }}

/** * The one script in this example: it keeps a weather volume over the camera. * * @remarks * This is the whole trick behind weather that never runs out. The volume is small — thirty metres * across — and it moves with the viewer, so the storm is always around them; and because both * documents simulate in **world space**, a drop that has already been emitted stays where it was * born instead of being dragged along. Moving the emitter therefore changes where the *next* drops * appear and nothing else. */import { f32, Script } from "ignifx";import type { Entity, ScriptCallbacks } from "ignifx";/** Keeps its entity directly above another one, at a fixed height. */export class FollowsTheViewer extends Script.define({ height: f32(12) }) implements ScriptCallbacks {  /** The namespaced registration id. */  static typeId = "weather/FollowsTheViewer";  /** Whose position to stand over. Assigned in code: an entity is not a schema field. */  target: Entity | null = null;  /** Moves the volume after the camera has moved, so the two never disagree within a frame. */  lateUpdate(): void {    const target = this.target;    if (target === null) {      return;    }    const at = target.transform.position;    this.transform.localPosition.set(at.x, this.height, at.z);  }}
